TYP DISK SEGMENT WITH THREADED
CORE, SEE SKETCH J2
THREAD SEGMENTS INTO EACH OTHER
TO ACHIEVE REQUIRED LENGTH
ATTACH SEGMENTS TO SUPPORT PLUG,
USE CLASS A PLUG (SKETCH J3) OR
CLASS B PLUG (SKETCH J4) AS REQUIRED.
SKETCH J1: SEGMENTED DISK ASSEMBLY ANODE
(MACHINE-FORMED INTERLOCKING CORES), TYPE ZDM
1. DISK SEGMENT NOMINAL SIZE SHALL MATCH NOMINAL
SIZE OF SUPPORT PLUG USED. SEE SKETCHES J2 - J4.
