MIL-DTL-18001 Anodes, Sacrificial Zinc AlloyThis specification covers the requirements for zinc anodes \(galvanic protectors\) in the form of plates, slabs, discs and rods for corrosion protection \(cathodic protection\) of metals and alloys. It also includes features of anode design and fabrication such as cast-in cores for mounting purposes. The material described by this specification contains elements for which the Occupational Safety and Health Administration \(OSHA\) has set standards for exposure limits. Handling, storage, and application of this material should be in accordance with the most recent Code of Federal Regulations Title 29, Part 1910 and 1915 and any other safety and health regulations \(local or otherwise\) which may apply.

Pages 1 - - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 - 32 - 33 - 34 - 35 - 36 - 37 - 38 - 39|||

�D1

LETTERING ON EXPOSED FACE

TABLE OF DIMENSIONS

GROOVED, SERRATED,

OR THREADED

METRIC

IMPERIAL

DIM

(INCH)

(MM)

PLAIN STEEL PIPE

6.00�.13

152.4�3.3

MOLD RAD

�D4

PERMITTED

DRAFT

1.00�.13

25.4�3.3

PERMITTED

.13�.06

3.3�1.5

.68�.02

17.3�.5

D4*

D5*

.42�.02

10.7�.5

.84�.02

21.3�.5

D4**

�D5

2X D3

D5**

.62�.02

15.7�.5

SECTION A-A

* CORRESPONDS TO ASTM A524

3/8" SCHED 80 OR BS EN 10305-1

18MM STEEL PIPE SIZES.

SKETCH F5: FAIRWATER SLAB, STYLE B,

** CORRESPONDS TO ASTM A524

6.00" DIAM (PIPE CORE), TYPE ZEP, 1.00" THICK

1/2" SCHED 40 OR BS EN 10305-1

MINIMUM WEIGHT = 7.2 LB / 3.3 KG

22MM STEEL PIPE SIZES.
